Pressurized Flat Plate SUS316L Solar Water Heater, a reliable and efficient solution for both commercial and household hot water needs. Built using durable and corrosion-resistant stainless steel materials (SUS316L inner tank), this high-performance system ensures long-term usage even under varying environmental conditions. With a 0.6MPa pressure tolerance, it is compatible with direct city water supply systems.
| Model: | FPC-150L | FPC-200L | FPC-300L |
| Volume: | 150L | 200L | 300L |
| Material of inner tank: | 1.2mm SUS316L | ||
| Material of outer tank: | 0.4mm Powder coated & UV resistant steel | ||
| Material of insulation: | 40mm Polyurethane | ||
| Electric resistance: | 1500W or 2400W, 220V | ||
| Working pressure: | Working pressure: ≤ 6 bar | ||
| Max testing pressure: | 10 bar | ||
| Size of pipe connection: | G 3/4” | ||
| Material of frame: | Coated galvanized sheet | ||
| Angle of frame: | 20° | ||
| Flat panel and gross area: | 1*2=2m² | 1*2.5=2.5m² | 2*2=4m² |
| 20GP/40GP/40HC Loading Qty: | 36/75/88 | 30/62/73 | 19/40/48 |
| Attribute | Specification |
|---|---|
| Type | Flat-Plate |
| Circulation Type | Indirect / Closed Loop (Active) |
| Tank Capacity | 300L |
| Application | Hotel, Garage, Commercial, Household |
| Power Source | Solar, Electric, Battery |
| Control | Not App-Controlled |
| Place of Origin | Jiangsu, China |
| Warranty | 3 Years |
| After-sales Service | Free Spare Parts |
| Installation Type | Freestanding |
| Connection Type | Direct-Plug |
Packaging and Delivery
Packaging:
LCL: Carton box + plywood case
FCL: Carton only
Port of Shipment: Lianyungang
Single Unit Package Size: 250 x 60 x 60 cm
Gross Weight: 198 kg
Production & Supply
Monthly Capacity: 5000 Sets
Customization Available (Minimum Order: 100 Sets):
Customized Logo
Customized Packaging
Graphic Customization
Lead Time Estimate
| Quantity | Lead Time |
|---|---|
| 1 – 100 sets | 15 days |
| 101 – 500 sets | 25 days |
| > 500 sets | Negotiable |
Container Loading Capacity
| Model | 20GP | 40GP | 40HC |
|---|---|---|---|
| FPC-150L | 36 | 75 | 88 |
| FPC-200L | 30 | 62 | 73 |
| FPC-300L | 19 | 40 | 48 |
SUNECO Solar Technology delivers high-performance solar water heating solutions tailored for residential, commercial, and industrial applications. With around-the-clock global support and a dedicated team, SUNECO ensures each system—from solar collectors to complete flat plate solar water heaters—is engineered for durability, energy efficiency, and long-term reliability. Every order is closely monitored from production to delivery, guaranteeing consistent quality and customer satisfaction.Specializing in advanced solar collectors and flat plate systems, SUNECO offers personalized solutions to meet specific installation needs. Whether it’s a solar water heater for home use or a custom thermal setup for a commercial facility,
